- Technical Parameters
Technical parameters E01A 7.5-14 MODEL PARAMETER TABLE Unit Data Setting range 1:X 1:125 Maximum flow rate in standard mode L/H 7.5 Maximum flow rate in 50% Viscosity mode L/H 3.75 Maximum flow rate in 25% Viscosity mode L/H 1.875 Minimum flow L/H 0.015 Maximum Output pressure Bar 14 Accuracy of repeatability1 %FS ±0.1-0.5 Max. suction lift during operation2 m 3 Min.pressure difference between inlet and outlet Bar 1 Max. Viscosity in 25% slow mode cP 1500 Max. Viscosity in 50% slow mode cP 800 Max. viscosity in standard mode cP 100 Type of inlet and outlet pipe / Hose Inlet and outlet pipe specifications mm 12×8 Minimum/Maximum liquid temperature for conveyance ℃ 0-45 Minimum/Maximum operating environment temperature ℃ 0-45 Max. altitude above sea level M 3200 Rated power W 120 - Performance and Configuration Notes
SPECIFIED DATA Flow Adjustment Method Panel manual control，modbus，4~20mA，0-10V，RS485 communication Control principle High precision stepper motor drives，advanced algorithm MOTOR type Stepper motor Supply Voltage 110-240V/50Hz Performance IP65 Function Manual mode，CONC Mode，Pulse mode，Current control，External Start/Stop，Slow mode and others Interface version Digital version (with all interfaces) Spare parts end materials: Pump head PVC（Standard）/ Optional PP and PVDF Diaphragm(s) PTFE Check valve PVDF Valve balls Zirconium Beads（standard） Gasket FPM Fluorine Rubber（Viton standard）/Optional OTFE，EPDM… YLC（pressure）sensor Continuously monitor pipeline pressure blockages and leaks,，insufficient chemical supply，diaphragm states
